CDQ3H Moulded Case Dual Power ATS
- Product Name: ATS Dual Power Automatic Transfer Switch
- Product Model: CDQ3HB
- Electrical classification: CB
- Standard: GB/T 14048.11 ĂIEC60947-6-1
- Use Classes: AC-33iB
- Pollution Level: Level 3
- Radiation Level: B
Overview
The Dual Power ATS current capacity is 63A, 100A, 250A, 400A, 630A, 800A. The electric operating mechanism is the motor (single-phase AC), which uses the forward and reverse of the motor to drive the opening and closing of the power supply.
About our company
Kemus is a leading provider of electrical switchgear and electronic components. Our products include circuit breakers, surge protectors, DC disconnect switch, contactors, relays, Dual Power ATS and indicators for voltage and fault detection.
Kemus insists on a comprehensive quality assurance system, ensuring our products meet global standards for safety and reliability.
Product Description
CDQ3H Moulded Case Dual Power ATS
Realize automatic switching between common power supply (I) and standby power supply (I) (can also be set to manual switching), because of power failure or abnormal (undervoltage, overvoltage, loss of voltage) between the power supply to ensure the continuity, reliability and safety of the power supply.
There are three operation modes for CDQ3HB Dual Power ATS automatic transfer switching equipment
● Automatic transfer mode controlled by the controller The controller can automatically detect the voltage loss, phase loss, undervoltage, and overvoltage faults of two-way power supply, and realize the automatic transfer between the power supplies according to the transfer mode and delay set by the user;
● Manual transfer mode via keys on the controller Press the [Auto/Manual] key on the controller panel to switch to the Manual mode (the automatic indicator is off); press the [Normal ON] or [Dual disconnect] or [Standby ON] key to switch the automatic transfer switching equipment to the corresponding power supply position;
● Manual transfer mode via the handle Press the [Auto/Manual] key on the controller panel to switch to the Manual mode (the auto indicator is off), or disconnect t he controller power. Take out the toggle handle from the body, and insert it into the rotation position of the body handle, press the handle to the bottom and turn it to t he required power position.
CDQ3HB Dual Power ATS Diagram
Dual Power ATS Legends:
1-Terminal block 2-Mounting hole 3-Company logo 4-Power end 5-Transfer position indicator window
6-Operating handle 7-Controller 8-Fuse tube 9-Company name 10-Product model
11-Split controller connecting cable
CDQ3H Dual Power ATS Fault analysis and Troubleshooting
Related Products
CDWNEGZ DC Disconnect Switch
Indoor Vacuum Circuit Breaker HFEV Series
CDQ3H Moulded Case Dual Power ATS
CDQ3H Dual Power ATS Maintenance and Service
● Maintenance and service must be conducted by the qualified professional;
● Make sure that the Dual Power ATS is de-energized during maintenance and service;
● Dual Power ATS can work reliably under the rated voltage (85%~110%) Ue. When connecting the wire during the installation of product, the inlet terminal, outlet terminal and phase N shall be strictly distinguished, and the neutral line shall not be shared.
● It is forbidden to operate this product out of the normal working conditions, such as no corresponding preventive measures taken for continuous moisture or condensation. There are combustible or corrosive dusts, the expected short-circuit current is out of range, the voltage is ultra-high or ultra-low, the current exceeds the rated current, and the altitude is ultra-high.
● Please use the special handle provided with the product for manual transfer operation.
● If the protective device is disconnected due to failure of line or load, first eliminate the fault, and then power on the load.
● Dual Power ATS shall be subject to the general inspection regularly during operation (such as every three months), and the power supply is transferred manually and automatically to check whether the product works normally.
